Engineering Graphics and Design (3110013)

BE | Semester-1   Winter-2019 | 09-01-2020

Q2) (c)

The end P of a line PQ 120 mm long is 30 mm above HP and 60 mm behind VP. The line is inclined at an angle of 30° with the reference plans of the projection. The point Q is below HP and behind VP. Draw the projections of line PQ and locate the point Q.
